Series : C3 grade load cell
Features : stainless steel weight sensor
Mounting Type : screw installation
Description : stainless steel C3 grade weight sensor, stainless steel load cell
Model Number : 6G
Type : Load Cell
Place of Origin : Guangdong, China
Brand Name : SNC
Use : weight measure
Theory : strain gauge load cell
Output : 2mv/v
Item : 6G
Accuracy : C3, C4, C5
Capacity : 10kg to 500kg
Material : 17-4 stainless steel
Excitation voltage : 5~12 VDC
recommended platform size : 400x400mm, 800x800mm
safe over load : 150% RO
IP grade : IP68, IP69
cable length : 3m
Application : platform scales, electronic scales, belt scales
MOQ : 4 pieces
Price : $135/pieces 4-39 pieces
Features:
Single point with parallel beam.
17-4PH stainless steel, hermetically welded, oil-proof, waterproof and anti-corrosion, Suitable for all kinds of environments.
Suitable for platform scales, electronic scales, belt scales and other electronic weighing devices.
Capacity:10kg to 500kg.
Recommended platform size: 400x400mm(10kg-100kgSE) / 800x800mm(75kg-500kg)
Diameters: mm
Parameters:
Capacity | kg | 10/20/50/75/100/150/200/300/400/500 | ||
Accuracy class | C3 | C4 | C5 | |
Maximum number | n max | $3,000 | $4,000 | $5,000 |
of verification intervals | ||||
Minimum load cell | v min | Emax/10000 | Emax/15000 | Emax/20000 |
verification interval | ||||
Combined error | (%FS) | ≤±0.0230 | ≤±0.0173 | ≤±0.0140 |
Creep | (%FS/30min) | ≤±0.0245 | ≤±0.0184 | ≤±0.0147 |
Temperature effect | (%FS/10℃) | ≤±0.0117 | ≤±0.0088 | ≤±0.0070 |
on sensitivity | ||||
Temperature | (%FS/10℃) | ≤±0.0140 | ≤±0.0093 | ≤±0.0070 |
effect on zero | ||||
Output sensitivity | (mv/v) | 2.0±0.2 | ||
Input resistance | (Ω) | 10kg-50kgSE/75kgSE/100kgSE | 75/100/150/-500kg | |
380±15 | 350±3.5 | |||
Output resistance | (Ω) | 350±3.5 | ||
Insulation resistance | (MΩ) | ≥5000(50VDC) | ||
Zero balance | (%FS) | ≤±2.0% | ||
Temperature, | (℃) | -10~+40 | ||
compensated | ||||
Temperature, operating | (℃) | -35~+70 | ||
Excitation, | (V) | 5~12(DC) | ||
Recommended | ||||
Excitation, Max | (V) | 18(DC) | ||
Safe overload | (%FS) | $150 | ||
Ultimate overload | (%FS) | $300 | ||
Protection Class | IP68/IP69K |
Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.
Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.
1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.
2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.
3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.
4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.
5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments
before shipping to our clients.
6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor
